Aeronautical Lab

STRENGTH OF MATERIALS LABORATORY

Universal Tensile Testing machine with double 1 shear attachment – 40 Ton Capacity
Torsion Testing Machine (60 NM Capacity)
Impact Testing Machine (300 J Capacity)
Brinell Hardness Testing Machine
Rockwell Hardness Testing Machine
Spring Testing Machine for tensile and compressive loads (2500 N)
Metallurgical Microscopes
Muffle Furnace (800 C)

FLUID MECHANICS AND MACHINERY LABORATORY

Orifice meter setup
Venturi meter setup
Rotameter setup
Pipe Flow analysis setup
Centrifugal pump/submergible pump setup
Reciprocating pump setup
Gear pump setup
Pelton wheel setup
Francis turbine setup
Kaplan turbine setup

THERMODYNAMICS LABORATORY

4 stroke twin cylinder diesel engine 1
Cut section model of 4 stroke diesel engine and cut section model of 2 stroke petrol engine
Parallel and counter flow heat exchanger test rig
Bomb Calorimeter
Vapour compression refrigeration test rig
Vapour compression air-conditioning test rig
Conductive heat transfer set up
Composite wall

AIRCRAFT STRUCTURES LABORATORY – I

100 kN Universal Testing Machine
2 Beams with weight hangers and dial gauges
Truss model and frame model
Column set up with dial gauges

AERODYNAMICS LABORATORY

Venturimeter
Orificemeter
Pipe friction apparatus
Subsonic Wind tunnel
Models(aerofoil, rough and smooth cylinder , flat plate)

AIRCRAFT STRUCTURES LABORATORY – II

Photo elasticity set up
Vibration set up with accesories
Wagner beam
Unsymmetrical bending set up
Set up for combined bending and torsion

PROPULSION LABORATORY

Goblin engine
Inline engine
Radial/ V- type engine
Jet facility with compressor and storage tank
Multitube manometer
Wind tunnel
0-5 bar pressure transducer with pressure indicator (or) DSA pressure scanner
Schlieren/ Shadowgraph set up
Ramjet facility
Conical flame holder
Compressor blade set

AERO ENGINE AND AIRFRAME LABORATORY

Aircraft Piston engines
Set of basic tools for dismantling and assembly
NDT equipment
Micrometers, depth gauges, vernier calipers
Valve timing disc
Shear cutter pedestal type
Drilling Machine
Bench Vices
Radius Bend bars
Pipe Flaring Tools
Welding machine
Glass fibre, epoxy resin
Strain gauges and strain indicator

AIRCRAFT SYSTEMS LABORATORY

Serviceable aircraft with all above systems
Hydraulic Jacks (Screw Jack)
Trestle adjustable
Spirit Level
Levelling Boards
Cable Tensiometer
Adjustable Spirit Level
Plumb Bob
